ZSOUND VCM - The Ultimate in Audio Performance

Elevate your sound experience with ZSOUND's VCM, designed for mid to large touring performances, stadiums, and theaters. The VCM boasts a coaxial structure with MF and HF drivers, delivering high-fidelity, low-frequency elasticity, and a slim, high-frequency profile.

Key Features:

• Wide Frequency Range: Coverage from 50Hz to 16kHz (±3dB), and 40Hz to 18kHz (-10dB), ensuring a rich and immersive audio experience.

• Adjustable Coverage: 100° horizontal coverage (adjustable), providing flexible sound distribution.

• High Sensitivity: At 1W/1m, the VCM delivers 112dB SPL for HF, 106dB SPL for MF, and 96dB SPL for LF.

• Power Handling: Capable of handling 120W/130W/800W power for HF/MF/LF respectively (AES standard), making it suitable for large-scale events.

• Optimized Impedance: 16Ω for HF/MF and LF, ensuring compatibility with a wide range of amplifiers.

Technical Specifications:

• Frequency Response: 50Hz to 16kHz (±3dB), 40Hz to 18kHz (-10dB)

• Coverage: 100° adjustable horizontal coverage

• Sensitivity (@1W/1m): HF: 112 dB SPL / MF: 106 dB SPL / LF: 96dB SPL

• Power Rating (AES): HF/MF/LF: 120W/130W/800W

• Impedance: HF/MF/LF: 16Ω

Physical Data:

• Dimensions (HxWxD): 177mm x 508mm x 711mm (7" x 20" x 28")

• Weight: 35kg / 77 lbs

• Connectors: 2 x NL8 connectors

Design Aesthetics:

• Materials: Baltic birch plywood

• Finish: Black polyurethane paint

• Grille: Charcoal with acoustically reticulated cloth

Application Scenarios:The VCM is perfect for large-scale events, outdoor performances, and professional installations where high-quality sound is paramount. Its adjustable angle allows for precise sound projection.
